Customer Care Schematics and Component Finder TFE-4/RV-1
Company Confidential
Issue 2.0 Mar/2005 Copyright © 2005 Nokia Corporation Page 9-14
Title: Component finder TF5_06
C216 H3 R142 L2 R329 M7
C107 F11 C217 H2 D300 P6 R143 N16 R404 E15
C108 C11 C218 H3 D301 M6 R144 N15 R405 E16
C109 D9 C219 H1 R145 F13 R406 E16
C110 Q17 C220 P4 E210 D22 R146 M16 R407 E16
C111 Q14 C221 H7 R200 C6 R408 E15
C113 Q10 C222 J1 L100 C10 R201 J3 R409 E14
C115 F13 C223 D8 L101 I10 R202 C6 R410 E14
C116 I16 C224 C8 L102 O9 R203 O4 R411 E14
C117 N11 C225 H7 L103 H16 R205 H2 R412 E14
C118 I12 C226 P4 L104 E13 R206 J3 R416 Q3
C119 I7 C227 H8 L200 C7 R207 O3 R419 D2
C120 M11 C228 C9 L201 D8 R208 C7 R420 D4
C122 F12 C229 D6 L202 D9 R209 H2
C123 L13 C230 E5 L203 E5 R211 H3 V100 D11
C126 J4 C231 F3 L204 E4 R212 H3 V101 F10
C128 H17 C234 G3 L205 J4 R213 N4 V104 H14
C129 D9 C235 E4 L207 I1 R215 H3 V105 F14
C130 E13 C236 F1 L208 I3 R216 G2 V107 F12
C133 G19 C238 C6 L209 I3 R217 J2 V108 L12
C134 G21 C239 C7 L401 E2 R218 J2 V112 J4
C135 D6 C240 J2 L402 E2 R219 P4 V115 C11
C137 J5 C241 J2 R220 P4 V116 L4
C139 L14 C242 N4 N100 J14 R221 P4 V117 O11
C140 K14 C245 J1 N101 M9 R222 D7 V118 L16
C141 O12 C246 I1 N103 I19 R224 G2 V119 N15
C142 F16 C247 G1 N104 O16 R226 G2 V120 L2
C143 L17 C248 I2 N200 I2 R227 F3 V121 K15
C145 O15 C249 J3 N201 F7 R228 G3 V122 N17
C146 O17 C250 I1 N202 F2 R229 I1 V123 K7
C147 O16 C251 I4 N300 R6 R230 I1 V124 K8
C148 F13 C252 I4 N301 K5 R231 I1 V300 Q4
C149 N16 C253 J3 N302 M7 R232 F1 V301 P5
C151 G18 C254 F2 R233 J3 V302 O5
C153 E13 C255 E2 R102 B10 R234 J3 V305 M4
C154 E12 C256 H7 R103 C12 R235 D5 V306 L1
C155 J13 C257 D7 R104 L11 R236 D4 V400 E15
C156 E12 C258 I5 R105 L4 R300 R6 V401 N15
C157 J14 C259 I2 R106 G14 R301 R4
C158 B11 C300 R5 R107 L11 R302 Q4 X103 B15
C159 B11 C301 K5 R109 K4 R303 B11 X104 A12
C160 B10 C302 N8 R110 F13 R304 M7 X105 B9
C161 L4 C303 N7 R111 L12 R305 R6 X106 A7
C162 H15 C304 L5 R113 F13 R306 Q5 X107 B4
C163 G17 C305 N6 R114 L13 R307 M8 X110 O2
C164 B10 C306 K1 R115 L13 R308 N7 X111 Q20
C165 H15 C307 Q4 R116 L4 R309 K6 X112 L20
C200 C6 C310 Q5 R120 J4 R310 K6 X209 B22
C201 C7 C311 K4 R122 G20 R311 P5 X210 Q23
C202 J3 C312 M7 R123 J4 R312 O5
C203 H2 C313 Q5 R125 J5 R313 N6
C204 I3 C314 N5 R126 G20 R314 M4
C205 H2 C404 E15 R131 O12 R315 M4
C206 O4 C405 E16 R132 O18 R316 M4
C207 O4 C406 E16 R133 N17 R317 Q6
C208 I3 C407 E16 R134 M17 R318 O4
C209 I3 C408 E15 R135 O15 R319 M5
C210 C7 C409 E15 R136 O17 R320 N6
C211 H3 C410 E15 R137 O15 R321 K1
C212 H2 C411 E14 R138 O15 R322 K1
C213 C6 C412 E14 R139 N17 R325 P4
C214 N4 C414 E2 R140 M16 R326 O4
C215 H3 C415 E2 R141 M15 R328 O4
CD
E
L
N
R
V
X
