Nokia 616 Service Manual

TFE-4/RV-1 Company Confidential
2 - Parts List Nokia Customer Care
Page 2-14 Copyright © 2005 Nokia Corporation Issue 2.0 Mar/2005
Company Confidential
Parts List for TF5 Module (JB)
PWB Components
Note: This table is for the N610, the N616 components are identical apart from those identified in the
table that follows this one.
Item
Location
Grid ref.
Description and value Type
C107 F 11 EL. CAP. 20% 50V 100u_50V 50V normal,-20%,20% ELCAP_SVP_F8
C108 C 11 Chipcap 5% NP0 22p 50V normal,-5%,5% 0402C
C109 D 9 CHIPCAP X7R 100N K 100n 50V normal,-20%,20% 0805C
C110 Q 17 ELCAP 470U +-20% 6V3 0R025 11.2X10.5 470u_6V3 6.3V normal,-20%,20% ELCAP_SVP_F8
C111 Q 14 ELCAP 470U +-20% 6V3 0R025 11.2X10.5 470u_6V3 6.3V normal,-20%,20% ELCAP_SVP_F8
C113 Q 10 CHIPCAP X5R 100N K 100n 10V normal,-10%,10% 0402C
C115 F 13 CHIPCAP X7R 220N M 220n 50V normal,-20%,20% 1206C_H0.95
C116 I 16 ELCAP CHIP 100u M 16V 105C 8X6.3 100u 16V normal,20%,20% CASE_MVK_H63
C117 N 11 Cer. cap 10% 10n 50V normal,-10%,10% 0603C
C118 I 12 EL. CAP. 20% 50V 100u 50V normal,-20%,20% ELCAP_SVP_F8
C119 I 7 EL. CAP. 20% 35V 330u 35V normal,-20%,20% Sanyo
C120 M 11 CHIPCAP X7R 100N K 100n 50V normal,-20%,20% 0805C
C122 F 12 CHIPCAP X5R 100N K 100n 10V normal,-10%,10% 0402C
C123 L 13 CHIPCAP X5R 100N K 100n 10V normal,-10%,10% 0402C
C126 J 4 CHIPCAP X5R 100N K 100n 10V normal,-10%,10% 0402C
C128 H 17 CHIPCAP X7R 100N K 100n 50V normal,-20%,20% 0805C
C129 D 9 Chipcap 5% X7R 220p 50V normal,-5%,5% 0402C
C130 E 13 CHIPCAP NP0 1N0 J 1n0 50V normal,-5%,5% 0603C
C133 G 19 CHIPCAP X7R 220N M 220n 50V normal,-20%,20% 1206C_H0.95
C134 G 21 EL. CAP. 20% 50V 100u_50V 50V normal,-20%,20% ELCAP_SVP_F8
C135 D 6 CHIPCAP X5R 1U K 1u0 16V normal,-10%,10% 0603C
C137 J 5 Chipcap X7R 10% 10n 16V normal,-10%,10% 0402C
C139 L 14 ELCAP CHIP 100u M 16V 105C 8X6.3 100u_16V 16V normal,20%,20% CASE_MVK_H63
C140 K 14 Chipcap 5% NP0 22p 50V normal,-5%,5% 0402C
C141 O 12 CHIPCAP NP0 1N0 J 1n0 50V normal,-5%,5% 0603C
C142 F 16 ELCAP CHIP 100u M 16V 105C 8X6.3 100u_16V 16V normal,20%,20% CASE_MVK_H63
C143 L 17 ELCAP CHIP 100u M 16V 105C 8X6.3 100u_16V 16V normal,20%,20% CASE_MVK_H63
C145 O 15 Chipcap X7R 10% 10n 16V normal,-10%,10% 0402C
C146 O 17 Chipcap X7R 10% 10n 16V normal,-10%,10% 0402C
C147 O 16 CHIPCAP X7R 100N K 100n 50V normal,-20%,20% 0805C
C148 F 13 CHIPCAP X7R 220N M 220n 50V normal,-20%,20% 1206C_H0.95
C149 N 16 CHIPCAP X5R 1U K 1u0 16V normal,-10%,10% 0603C
C151 G 18 CHIPCAP X7R 220N M 220n 50V normal,-20%,20% 1206C_H0.95
C153 E 13 Chipcap 5% NP0 22p 50V normal,-5%,5% 0402C
C154 E 12 CHIPCAP X5R 1U M 50V 1210 1u 50V normal,-20%,20% 1210C_H2.8
C155 J 13 CHIPCAP X5R 1U M 50V 1210 1u 50V normal,-20%,20% 1210C_H2.8

Nokia 616 Specifications

General

Brand	Nokia
Model	616
Category	Automobile Electronics
Language	English
