Nokia 616 Service Manual

Nokia Customer Care 2 - Parts List
Company Confidential TFE-4/RV-1
Issue 2.0 Mar/2005 Copyright © 2005 Nokia Corporation Page 2-15
Company Confidential
C156 E 12 CHIPCAP X7R 100N K 100n 50V normal,-20%,20% 0805C
C157 J 14 Chipcap 5% NP0 22p 50V normal,-5%,5% 0402C
C158 B 11 CHIPCAP X5R 1U M 50V 1210 1u 50V normal,-20%,20% 1210C_H2.8
C159 B 11 Chipcap 5% NP0 22p 50V normal,-5%,5% 0402C
C160 B 10 Cer. cap 10% 10n 50V normal,-10%,10% 0603C
C161 L 4 Chipcap X7R 10% 10n 16V normal,-10%,10% 0402C
C162 H 15 Chipcap X7R 10% 10n 16V normal,-10%,10% 0402C
C163 G 17 Chipcap 5% X7R 220p 50V normal,-5%,5% 0402C
C164 B 10 Chipcap 5% X7R 220p 50V normal,-5%,5% 0402C
C165 H 15 Chipcap 5% X7R 220p 50V normal,-5%,5% 0402C
C200 C 6 CHIPCAP X5R 10U K 10u 10V normal,-10%,10% 1206C_TDK
C201 C 7 Chipcap 5% NP0 22p 50V normal,-5%,5% 0402C
C202 J 3 CHIPCAP X5R 1U K 1u0 16V normal,-10%,10% 0603C
C203 H 2 Chipcap 5% X7R 220p 50V normal,-5%,5% 0402C
C204 I 3 Chipcap 5% NP0 22p 50V normal,-5%,5% 0402C
C205 H 2 Chipcap 5% NP0 22p 50V normal,-5%,5% 0402C
C206 O 4 Chipcap X7R 10% 10n 16V normal,-10%,10% 0402C
C207 O 4 Chipcap 5% X7R 220p 50V normal,-5%,5% 0402C
C208 I 3 Chipcap 5% NP0 22p 50V normal,-5%,5% 0402C
C209 I 3 Chipcap 5% NP0 22p 50V normal,-5%,5% 0402C
C210 C 7 CHIPCAP X7R 220N M 220n 50V normal,-20%,20% 1206C_H0.95
C211 H 3 CHIPCAP X5R 1U K 1u0 16V normal,-10%,10% 0603C
C212 H 2 Chipcap 5% NP0 22p 50V normal,-5%,5% 0402C
C213 C 6 CHIPCAP NP0 1N0 J 1n0 50V normal,-5%,5% 0603C
C214 N 4 Chipcap X7R 10% 10n 16V normal,-10%,10% 0402C
C215 H 3 Chipcap 5% NP0 22p 50V normal,-5%,5% 0402C
C216 H 3 Chipcap 5% NP0 22p 50V normal,-5%,5% 0402C
C217 H 2 Chipcap 5% NP0 22p 50V normal,-5%,5% 0402C
C218 H 3 Chipcap 5% NP0 22p 50V normal,-5%,5% 0402C
C219 H 1 Chipcap X7R 10% 10n 16V normal,-10%,10% 0402C
C220 P 4 Chipcap 5% X7R 1n5 50V normal,-5%,5% 0402C
C221 H 7 CHIPCAP X5R 100N K 100n 10V normal,-10%,10% 0402C
C222 J 1 Chipcap X7R 10% 10n 16V normal,-10%,10% 0402C
C223 D 8 Chipcap 5% X7R 220p 50V normal,-5%,5% 0402C
C224 C 8 CHIPCAP NP0 1N0 J 1n0 50V normal,-5%,5% 0603C
C225 H 7 CHIPCAP X5R 100N K 100n 10V normal,-10%,10% 0402C
C226 P 4 Chipcap 5% X7R 1n5 50V normal,-5%,5% 0402C
C227 H 8 Chipcap 5% X7R 220p 50V normal,-5%,5% 0402C
C228 C 9 CHIPCAP NP0 1N0 J 1n0 50V normal,-5%,5% 0603C
C229 D 6 CHIPCAP X5R 10U K 10u 10V normal,-10%,10% 1206C_TDK
C230 E 5 Chipcap 5% NP0 22p 50V normal,-5%,5% 0402C
Item
Location
Grid ref.
Description and value Type
