Nokia 616 Service Manual

TFE-4/RV-1 Company Confidential
2 - Parts List Nokia Customer Care
Page 2-16 Copyright © 2005 Nokia Corporation Issue 2.0 Mar/2005
Company Confidential
C231 F 3 CHIPCAP X5R 100N K 100n 10V normal,-10%,10% 0402C
C234 G 3 CHIPCAP X5R 100N K 100n 10V normal,-10%,10% 0402C
C235 E 4 Chipcap 5% NP0 22p 50V normal,-5%,5% 0402C
C236 F 1 CHIPCAP X5R 1U K 1u0 16V normal,-10%,10% 0603C
C238 C 6 Chipcap 5% NP0 22p 50V normal,-5%,5% 0402C
C239 C 7 Chipcap 5% NP0 22p 50V normal,-5%,5% 0402C
C240 J 2 CHIPCAP X5R 1U K 1u0 16V normal,-10%,10% 0603C
C241 J 2 CHIPCAP X5R 100N K 100n 10V normal,-10%,10% 0402C
C242 N 4 Chipcap 5% X7R 220p 50V normal,-5%,5% 0402C
C245 J 1 CHIPCAP X5R 100N 100n 10V normal,-10%,10% 0402C
C246 I 1 CHIPCAP X7R 33N K 33n 10V normal,-10%,10% 0402C
C247 G 1 CHIPCAP X5R 1U K 1u0 16V normal,-10%,10% 0603C
C248 I 2 Chipcap X7R 10% 330p 50V normal,-10%,10% 0402C
C249 J 3 CHIPCAP X5R 1U K 1u0 16V normal,-10%,10% 0603C
C250 I 1 Chipcap X7R 10% 330p 50V normal,-10%,10% 0402C
C251 I 4 CHIPCAP X5R 1U K 1u0 16V normal,-10%,10% 0603C
C252 I 4 Chipcap X7R 10% 10n 16V normal,-10%,10% 0402C
C253 J 3 Chipcap X7R 10% 10n 16V normal,-10%,10% 0402C
C254 F 2 CHIPCAP X5R 100N K 100n 10V normal,-10%,10% 0402C
C255 E 2 CHIPCAP X5R 10U K 10u 10V normal,-10%,10% 1206C_TDK
C256 H 7 CHIPCAP X7R 100N K 100n 50V normal,-20%,20% 0805C
C257 D 7 CHIPCAP X7R 100N K 100n 50V normal, -20%,20% 0805C
C258 I 5 ELCAP CHIP 100u M 16V 105C 8X6.3 100u_16V 16V normal, -20%,20% CASE_MVK_H63
C259 I 2 Chipcap X7R 10% 330p 50V normal,-10%,10% 0402C
C300 R 5 CHIPCAP X5R 1U M 50V 1210 1u 50V normal,-20%,20% 1210C_H2.8
C301 K 5 CHIPCAP X5R 1U K 1u0 16V normal,-10%,10% 0603C
C302 N 8 CHIPCAP X7R 100N K 100n 50V normal,-20%,20% 0805C
C303 N 7 CHIPCAP X5R 1U K 1u0 16V normal,-10%,10% 0603C
C304 L 5 CHIPCAP X5R 100N K 100n 10V normal,-10%,10% 0402C
C305 N 6 CHIPCAP X5R 1U K 1u0 16V normal,-10%,10% 0603C
C306 K 1 Chipcap X7R 10% 10n 16V normal,-10%,10% 0402C
C307 Q 4 CHIPCAP NP0 1N0 J 1n0 50V normal,-5%,5% 0603C
C310 Q 5 CHIPCAP X5R 100N K 100n 10V normal,-10%,10% 0402C
C311 K 4 CHIPCAP X5R 100N K 100n 10V normal,-10%,10% 0402C
C312 M 7 CHIPCAP X5R 100N K 100n 10V normal,-10%,10% 0402C
C313 Q 5 CHIPCAP X5R 100N K 100n 10V normal,-10%,10% 0402C
C314 N 5 CHIPCAP X5R 100N K 100n 10V normal,-10%,10% 0402C
C404 E 15 Chipcap 5% NP0 22p 50V normal,-5%,5% 0402C
C405 E 16 Chipcap 5% NP0 22p 50V normal,-5%,5% 0402C
C406 E 16 Chipcap X7R 10% 10n 16V normal,-10%,10% 0402C
C407 E 16 Chipcap 5% NP0 22p 50V normal,-5%,5% 0402C
Item
Location
Grid ref.
Description and value Type
