Nokia 616 Service Manual

Nokia Customer Care 2 - Parts List
Company Confidential TFE-4/RV-1
Issue 2.0 Mar/2005 Copyright © 2005 Nokia Corporation Page 2-17
Company Confidential
C408 E 15 Chipcap 5% NP0 22p 50V normal,-5%,5% 0402C
C409 E 15 Chipcap 5% NP0 22p 50V normal,-5%,5% 0402C
C410 E 15 Chipcap 5% NP0 22p 50V normal,-5%,5% 0402C
C411 E 14 Chipcap 5% NP0 22p 50V normal,-5%,5% 0402C
C412 E 14 Chipcap 5% X7R 220p 50V normal,-5%,5% 0402C
C414 E 2 Chipcap 5% NP0 22p 50V normal,-5%,5% 0402C
C415 E 2 Chipcap 5% NP0 22p 50V normal,-5%,5% 0402C
D300 P 6 SN74AHC08D 4X2INPUT AND SO14 ~ ~ ~ SO14N
D301 M 6 CMOS Timer ~ ~ ~ SO8N
E210 D 22 EXACTALLOY SOLDER PREFORM ~ ~ ~ ALPHA_SOLDER
L100 C 10 FERRITE BEAD 68R/100MHZ 3A 1206 68R/100MHz ~ _ FERRITE_EXCML32
L101 I 10 CHOKE 33UH M 3.0A 65MR 12X12 SMD 33uH ~ normal,-20%,20% INDUCTOR_CDRH127
L102 O 9 CHOKE 33UH M 3.0A 65MR 12X12 SMD 33uH ~ normal,-20%,20% INDUCTOR_CDRH127
L103 H 16 CHOKE 2U2 M 0R07 2.3A 6.6X4.45 2u2H ~ normal,-20%,20% DS1608C
L104 E 13 FERRITE BEAD 68R/100MHZ 3A 1206 68R/100MHz ~ _ FERRITE_EXCML32
L200 C 7 FERRITE BEAD 0R6 600R/100MHz ~ ~ FERRITE_0402
L201 D 8 FERRITE BEAD 68R/100MHZ 3A 1206 68R/100MHz ~ _ FERRITE_EXCML32
L202 D 9 FERRITE BEAD 68R/100MHZ 3A 1206 68R/100MHz ~ _ FERRITE_EXCML32
L203 E 5 FERRITE BEAD 0R6 600R/100M 600R/100MHz ~ ~ FERRITE_0402
L204 E 4 FERRITE BEAD 0R6 600R/100M 600R/100MHz ~ ~ FERRITE_0402
L205 J 4 FERRITE BEAD 0R6 600R/100M 600R/100MHz ~ _ FERRITE_0402
L207 I 1 CHIP COIL 33N J Q7/100MHZ 33nH ~ normal,-5%,5% 0402_ELJRF
L208 I 3 CHIP COIL 33N J Q7/100MHZ 33nH ~ normal,-5%,5% 0402_ELJRF
L209 I 3 CHIP COIL 33N J Q7/100MHZ 33nH ~ normal,-5%,5% 0402_ELJRF
L401 E 2 FERRITE BEAD 0R6 600R/100M 600R/100MHz ~ normal,-5%,5% FERRITE_0402
L402 E 2 FERRITE BEAD 0R6 600R/100M 600R/100MHz ~ normal,-5%,5% FERRITE_0402
N100 J 14 LM2936 VOLT REG 5V 3% 50MA SO8 ~ ~ ~ SO8N
N101 M 9 SW REG 1.2-37V 3A LM2676
TO263-7
~ ADJ ~ TO263_7
N103 I 19 LM2941S 1Z SMD ADJ VOLTAGE ~ ~ ~ TO_263_5
N104 O 16 VCOMP 15MV LMC7211B SOT23-5 ~ ~ ~ SOT23_5
N200 I 2 4XOPAMP 2.7-12V TS974 ~ ~ ~ SO14N
N201 F 7 TDA7391PD BR AUDIO AMP 32W ~ ~ ~ PSO_20
N202 F 2 LM4864 AF PW AMP 2.7-5.5V 0W3 ~ ~ ~ SO8S
N300 R 6 LMC7215IM5X COMPARATOR 2-8V ~ ~ ~ SOT23_5_H1.45
N301 K 5 LMC7215IM5X COMPARATOR 2-8V ~ ~ ~ SOT23_5_H1.45
N302 M 7 LMC7215IM5X COMPARATOR 2-8V ~ ~ ~ SOT23_5_H1.45
R102 B 10 CHIP VARISTOR VWM18V VC50V 18V ~ - 0603_VAR
R103 C 12 CHIP VARISTOR VWM18V VC50V 18V ~ - 0603_VAR
R104 L 11 CHIPRES 0W06 2K87 F 200PPM 2k87 ~ normal,-1%,1% 0402R
R105 L 4 CHIPRES 0W06 1K0 F 200PPM 1k0 ~ normal,-1%,1% 0402R
Item
Location
Grid ref.
Description and value Type
