Nokia 616 Service Manual

TFE-4/RV-1 Company Confidential
2 - Parts List Nokia Customer Care
Page 2-18 Copyright © 2005 Nokia Corporation Issue 2.0 Mar/2005
Company Confidential
R106 G 14 Resistor 1% 63mW 220k ~ normal,-1%,1% 0402R
R107 L 11 CHIPRES 0W06 1K1 F 250PPM 1k1 ~ normal,-1%,1% 0402R
R109 K 4 Resistor 5% 63mW 100k ~ normal,-5%,5% 0402R
R110 F 13 Resistor 5% 63mW 10k ~ normal,-5%,5% 0402R
R111 L 12 Resistor 1% 63mW 3k9 ~ normal,-1%,1% 0402R
R113 F 13 CHIPRES 0W06 1K0 F 200PPM 1k0 ~ normal,-1%,1% 0402R
R114 L 13 Resistor 5% 63mW 47k ~ normal,-5%,5% 0402R
R115 L 13 Resistor 5% 63mW 47k ~ normal,-5%,5% 0402R
R116 L 4 CHIPRES 0W06 1K0 F 200PPM 1k0 ~ normal,-1%,1% 0402R
R120 J 4 Resistor 5% 63mW 100k ~ normal,-5%,5% 0402R
R122 G 20 Chipres 0W06 6k8 F 6k8 ~ normal,-1%,1% 0402R
R123 J 4 CHIPRES 0W06 3K3 F 3k3 ~ normal,-1%,1% 0402R
R125 J 5 Resistor 5% 63mW 10k ~ normal,-5%,5% 0402R
R126 G 20 CHIPRES 0W06 1K0 F 200PPM 1k0 ~ normal,-1%,1% 0402R
R131 O 12 Resistor 5% 100mW 10R ~ normal,-5%,+5% 0603R
R132 O 18 CHIPRES 0W06 3K3 F 3k3 ~ normal,-1%,1% 0402R
R133 N 17 CHIPRES 0W06 150K F 200PPM 150k ~ normal,-1%,1% 0402R
R134 M 17 CHIPRES 0W5 0R1 G 0R1 ~ normal,-2%,2% 1210_R
R135 O 15 Resistor 5% 63mW 10k ~ normal,-5%,5% 0402R
R136 O 17 Resistor 5% 63mW 10k ~ normal,-5%,5% 0402R
R137 O 15 Resistor 5% 63mW 100R ~ normal,-5%,5% 0402R
R138 O 15 Resistor 5% 63mW 100R ~ normal,-5%,5% 0402R
R139 N 17 Resistor 5% 63mW 47k ~ normal,-5%,5% 0402R
R140 M 16 Resistor 1% 63mW 220k ~ normal,-1%,1% 0402R
R141 M 15 Resistor 5% 63mW 47k ~ normal,-5%,5% 0402R
R142 L 2 Resistor 5% 63mW 47k ~ normal,-5%,5% 0402R
R143 N 16 CHIPRES 0W06 1K0 F 200PPM 1k0 ~ normal,-1%,1% 0402R
R144 N 15 CHIPRES 0W06 1K0 F 200PPM 1k0 ~ normal,-1%,1% 0402R
R145 F 13 Resistor 5% 63mW 10k ~ normal,-5%,5% 0402R
R146 M 16 Resistor 1% 63mW 220k ~ normal,-1%,1% 0402R
R200 C 6 Resistor 5% 63mW 330R ~ normal,-5%,5% 0402R
R201 J 3 Resistor 5% 63mW 5k6 ~ normal,-5%,5% 0402R
R202 C 6 Resistor 5% 63mW 1k8 ~ normal,-5%,5% 0402R
R203 O 4 Resistor 5% 63mW 100R ~ normal,-5%,5% 0402R
R205 H 2 CHIPRES 0W06 120K F 200PPM 120k ~ normal,-1%,1% 0402R
R206 J 3 Resistor 5% 63mW 10k ~ normal,-5%,5% 0402R
R207 O 3 Resistor 5% 63mW 3k9 ~ normal,-5%,5% 0402R
R208 C 7 CHIPRES 0W06 1K0 F 200PPM 1k0 ~ normal,-1%,1% 0402R
R209 H 2 Chipres 0W06 6k8 F 6k8 ~ normal,-1%,1% 0402R
R211 H 3 Chipres 0W06 22k F 200ppm 22k ~ normal,-1%,1% 0402R
R212 H 3 Chipres 0W06 22k F 200ppm 22k ~ normal,-1%,1% 0402R
Item
Location
Grid ref.
Description and value Type
