Nokia 616 Service Manual

Nokia Customer Care 2 - Parts List
Company Confidential TFE-4/RV-1
Issue 2.0 Mar/2005 Copyright © 2005 Nokia Corporation Page 2-19
Company Confidential
R213 N 4 Resistor 5% 63mW 100R ~ normal,-5%,5% 0402R
R215 H 3 Resistor 5% 63mW 10k ~ normal,-5%,5% 0402R
R216 G 2 Resistor 5% 63mW 10k ~ normal,-5%,5% 0402R
R217 J 2 Chipres 0W06 22k F 200ppm 22k ~ normal,-1%,1% 0402R
R218 J 2 Chipres 0W06 22k F 200ppm 22k ~ normal,-1%,1% 0402R
R219 P 4 CHIPRES 0W06 1K0 F 200PPM 1k0 ~ normal,-1%,1% 0402R
R220 P 4 CHIPRES 0W06 2K87 F 200PPM 2k87 ~ normal,-1%,1% 0402R
R221 P 4 CHIPRES 0W06 1K0 F 200PPM 1k0 ~ normal,-1%,1% 0402R
R222 D 7 Resistor 5% 63mW 47k ~ normal,-5%,5% 0402R
R224 G 2 CHIPRES 0W06 10K F 10k ~ normal,-1%,1% 0402R
R226 G 2 CHIPRES 0W06 10K F 10k ~ normal,-1%,1% 0402R
R227 F 3 Chipres 0W06 J 4R7 ~ normal,-5%,+5% 0603R
R228 G 3 Chipres 0W06 J 4R7 ~ normal,-5%,+5% 0603R
R229 I 1 Chipres 0W06 22k F 200ppm 22k ~ normal,-1%,1% 0402R
R230 I 1 Chipres 0W06 22k F 200ppm 22k ~ normal,-1%,1% 0402R
R231 I 1 Resistor 5% 63mW 47k ~ normal,-5%,5% 0402R
R232 F 1 CHIPRES 0W06 10K F 10k ~ normal,-1%,1% 0402R
R233 J 3 Resistor 5% 63mW 47k ~ normal,-5%,5% 0402R
R234 J 3 Resistor 5% 63mW 47k ~ normal,-5%,5% 0402R
R235 D 5 Resistor 5% 63mW 100R ~ normal,-5%,5% 0402R
R236 D 4 Resistor 5% 63mW 100R ~ normal,-5%,5% 0402R
R300 R 6 CHIPRES 0W06 120K F 200PPM 120k ~ normal,-1%,1% 0402R
R301 R 4 Resistor 1% 63mW 220k ~ normal,-1%,1% 0402R
R302 Q 4 Resistor 5% 63mW 10k ~ normal,-5%,5% 0402R
R303 B 11 Chipres 0W06 22k F 200ppm 22k ~ normal,-1%,1% 0402R
R304 M 7 CHIPRES 0W06 10K F 10k ~ normal,-1%,1% 0402R
R305 R 6 CHIPRES 0W06 120K F 200PPM 120k ~ normal,-1%,1% 0402R
R306 Q 5 CHIPRES 0W06 120K F 200PPM 120k ~ normal,-1%,1% 0402R
R307 M 8 Resistor 5% 63mW 5k6 ~ normal,-5%,5% 0402R
R308 N 7 CHIPRES 0W06 10K F 10k ~ normal,-1%,1% 0402R
R309 K 6 Resistor 1% 63mW 220k ~ normal,-1%,1% 0402R
R310 K 6 CHIPRES 0W06 39K F 39k ~ normal,-1%,1% 0603R_ROHM
R311 P 5 Resistor 5% 63mW 47k ~ normal,-5%,5% 0402R
R312 O 5 Resistor 5% 63mW 10k ~ normal,-5%,5% 0402R
R313 N 6 Resistor 1% 63mW 680k ~ normal,-1%,1% 0402R
R314 M 4 Resistor 5% 63mW 47k ~ normal,-5%,5% 0402R
R315 M 4 Resistor 5% 63mW 10k ~ normal,-5%,5% 0402R
R316 M 4 Resistor 5% 63mW 47k ~ normal,-5%,5% 0402R
R317 Q 6 Resistor 5% 63mW 10k ~ normal,-5%,5% 0402R
R318 O 4 CHIPRES 0W06 1K0 F 200PPM 1k0 ~ normal,-1%,1% 0402R
R319 M 5 Resistor 5% 63mW 10k ~ normal,-5%,5% 0402R
Item
Location
Grid ref.
Description and value Type
