Nokia Customer Care 4 - Service Tools
Company Confidential TFE-4/RV-1
Issue 2.0 Mar/2005 Copyright © 2005 Nokia Corporation Page 4-3
Company Confidential
List of Service Tools
Type Designator Description Functionality
FLS-4S Flash Adapter for EMEA To flash product SW into the product
FPS-8 Flash Prommer To flash product SW into the product.
Service tool for high level service. Power is suplied to the
FPS-8 from the ACF-8 .
The sales pack contains:
• FPS-8 Flash Prommer
• FPS-8 Activation sheet
• ACF-8 Power Supply
• AXS-4 Service Cable (D9-D9)
• Printer cable
FPS-10 Flash Prommer To flash product SW into the DCT-4 and BB5 products.
Service tool for high level service, can replace the FPS-8
Flash Prommer.
The sales pack contains:
• FPS-10 Flash Prommer
• AC-33 Power Supply and cables
• USB Cable CA-31D
Note: The FPS-10 requires the following power cables:
• JBV-1/DA-18 concept CA-41PS
• FLA-41 concept CA-35S
