Nokia 616 Service Manual

TFE-4/RV-1 Company Confidential
2 - Parts List Nokia Customer Care
Page 2-20 Copyright © 2005 Nokia Corporation Issue 2.0 Mar/2005
Company Confidential
R320 N 6 Resistor 1% 63mW 680k ~ normal,-1%,1% 0402R
R321 K 1 Resistor 5% 63mW 10k ~ normal,-5%,5% 0402R
R322 K 1 Resistor 5% 63mW 10k ~ normal,-5%,5% 0402R
R325 P 4 Resistor 5% 63mW 100k ~ normal,-5%,5% 0402R
R326 O 4 CHIPRES 0W06 2K87 F 200PPM 2k87 ~ normal,-1%,1% 0402R
R328 O 4 Resistor 5% 63mW 10k ~ normal,-5%,5% 0402R
R329 M 7 Resistor 5% 63mW 10k ~ normal,-5%,5% 0402R
R404 E 15 Resistor 5% 63mW 100R ~ normal,-5%,5% 0402R
R405 E 16 Resistor 5% 63mW 100R ~ normal,-5%,5% 0402R
R406 E 16 Resistor 5% 63mW 100R ~ normal,-5%,5% 0402R
R407 E 16 VARISTOR ARRAY 2XVWM16V VC50 2XVWM16V ~ ~ 0405_2
R408 E 15 Resistor 5% 63mW 100R ~ normal,-5%,5% 0402R
R409 E 14 Resistor 5% 63mW 100R ~ normal,-5%,5% 0402R
R410 E 14 Resistor 5% 63mW 100R ~ normal,-5%,5% 0402R
R411 E 14 Resistor 5% 63mW 100R ~ normal,-5%,5% 0402R
R412 E 14 Resistor 5% 63mW 47k ~ normal,-5%,5% 0402R
R416 Q 3 Resistor 5% 63mW 47k ~ normal,-5%,5% 0402R
R419 D 2 VARISTOR ARRAY 2XVWM16V VC50 2XVWM16V ~ ~ 0405_2
R420 D 4 VARISTOR ARRAY 2XVWM16V VC50 2XVWM16V ~ ~ 0405_2
V100 D 11 SCH DI 40V 3A DO214AB ~ ~ ~ DO_214AB
V101 F 10 TVS DI SMAJ30A 30V 5.8A 300W SMA ~ ~ ~ DO_214AC
V104 H 14 FET RFD8P05SM P 8A 50V 0R3 TO252AA ~ ~ ~ TO_252AA
V105 F 14 Zener_diode ~ ~ ~ SOT23
V107 F 12 TR 2SC5658QRS N 50V 0A1 0W15 ~ ~ ~ VMT3
V108 L 12 MFETX2 UM6K1N N 30V 0.1A 7R SC-88 ~ ~ ~ UMT6
V112 J 4 MFETX2 FDG6322C BIP.REPLAC ~ ~ ~ SOT_363
V113 K 8 TR 2SC5658QRS N 50V 0A1 0W15 ~ ~ ~ VMT3
V115 C 11 TVS DI SMAJ30A 30V 5.8A 300W SMA ~ ~ ~ DO_214AC
V116 L 4 MFETX2 FDG6322C BIP.REPLAC ~ ~ ~ SOT_363
V117 O 11 SCH DI 40V 3A ~ ~ ~ DO_214AB
V118 L 16 FET RFD10P03L P 30V 10A 0.2R ~ ~ ~ TO_252AA
V119 N 15 SCHDIX2 BAS70-07W 70V 70MA ~ ~ ~ SOT343_R
V120 L 2 TRX2+RX4 UMH9N 50V 0.1A ~ ~ ~ SOT_363
V121 K 15 SCH DI RB491D 20V 1A VF<0.45 ~ ~ ~ SC59
V122 N 17 SCHDIX2 BAS70-07W 70V 70MA ~ ~ ~ SOT343_R
V123 K 7 MFET BUK107-50DL N 50V 0A7 ~ ~ ~ SOT223_SIE
V124 K 8 SCH DI RB491D 20V 1A VF<0.45 ~ ~ ~ SC59
V300 Q 4 SCHDIX2 BAS70-07W 70V 70MA ~ ~ ~ SOT343_R
V301 P 5 SCHDIX2 BAS70-07W 70V 70MA ~ ~ ~ SOT343_R
V302 O 5 MFETX2 FDG6322C BIP.REPLAC ~ ~ ~ SOT_363
V305 M 4 TRX2+RX4 UMH9N 50V 0.1A ~ ~ ~ SOT_363
