Nokia 616 Service Manual

TFE-4/RV-1 Company Confidential
2 - Parts List Nokia Customer Care
Page 2-6 Copyright © 2005 Nokia Corporation Issue 2.0 Mar/2005
Company Confidential
C279 Top P 5 CHIPCAP X5R 1u0 6.3V normal,-10%,10% 0603C
C280 Top P 7 CHIPCAP X5R 1u0 6.3V normal,-10%,10% 0603C
C281 Top P 5 CHIPCAP X5R 1u0 6.3V normal,-10%,10% 0603C
C282 Top O 3 CHIPCAP X5R 1u0 6.3V normal,-10%,10% 0603C
C283 Top P 2 CHIPCAP X5R 1u0 6.3V normal,-10%,10% 0603C
C284 Top P 3 CHIPCAP X5R 1u0 6.3V normal,-10%,10% 0603C
C285 Top O 6 CHIPCAP X5R 1u0 6.3V normal,-10%,10% 0603C
C286 Top N 6 CHIPCAP X5R 1u0 6.3V normal,-10%,10% 0603C
C287 Top N 7 CHIPCAP X5R 1u0 6.3V normal,-10%,10% 0603C
C288 Top N 7 CHIPCAP X5R 1u0 6.3V normal,-10%,10% 0603C
C289 Top O 6 CHIPCAP X5R 1u0 6.3V normal,-10%,10% 0603C
C290 Top P 6 CHIPCAP X5R 1u0 10V normal,-10%,10% 0603C_H0.95
C291 Top O 6 CHIPCAP X5R 1u0 6.3V normal,-10%,10% 0603C
C292 Top P 6 CHIPCAP X5R 1u0 10V normal,-10%,10% 0603C_H0.95
C293 Top P 7 CHIPCAP X5R 1u0 6.3V normal,-10%,10% 0603C
C294 Top O 7 CHIPCAP X5R 1u0 6.3V normal,-10%,10% 0603C
C295 Top N 6 CHIPCAP X5R 1u0 6.3V normal,-10%,10% 0603C
C296 Top O 7 CHIPCAP X5R 1u0 6.3V normal,-10%,10% 0603C
C297 Top N 6 CHIPCAP X5R 1u0 6.3V normal,-10%,10% 0603C
C298 Top O 7 CHIPCAP X5R 1u0 6.3V normal,-10%,10% 0603C
C299 Top N 7 CHIPCAP X5R 1u0 6.3V normal,-10%,10% 0603C
C306 Top F 1 Chipcap 5% NP0 27p 50V normal,-5%,5% 0402C
C307 Top F 1 Chipcap 5% NP0 27p 50V normal,-5%,5% 0402C
C308 Top G 1 Chipcap 5% NP0 27p 50V normal,-5%,5% 0402C
C309 Top G 9 Chipcap 5% NP0 27p 50V normal,-5%,5% 0402C
C310 Top F 9 Chipcap 5% NP0 27p 50V normal,-5%,5% 0402C
C311 Top F 9 Chipcap 5% NP0 27p 50V normal,-5%,5% 0402C
C312 Top G 1 Chipcap 5% NP0 27p 50V normal,-5%,5% 0402C
C313 Top G 9 Chipcap 5% NP0 27p 50V normal,-5%,5% 0402C
C390 Top U 5 CHIPCAP X5R 100n 10V normal,-10%,10% 0402C
C400 Top P 7 Chipcap X7R 10n 16V normal,-10%,10% 0402C
C401 Top Q 5 CHIPCAP X5R 100n 10V normal,-10%,10% 0402C
C402 Top R 5 Chipcap X7R 10n 16V normal,-10%,10% 0402C
C403 Top Q 5 Chipcap X7R 10n 16V normal,-10%,10% 0402C
C404 Top R 5 Chipcap X7R 10n 16V normal,-10%,10% 0402C
C405 Top R 8 Chipcap X7R 10n 16V normal,-10%,10% 0402C
C420 Top L 5 Chipcap 5% NP0 12p 50V normal,-5%,5% 0402C
C450 Top U 6 Chipcap X7R 10n 16V normal,-10%,10% 0402C
C451 Top U 6 CHIPCAP X5R 100n 10V normal,-10%,10% 0402C
C454 Top S 5 CHIPCAP X7R 100n 16V normal,-10%,10% 0603_BLM
Item
Location
Side, Grid ref
Description and value Type
