Nokia 616 Service Manual

Nokia Customer Care 2 - Parts List
Company Confidential TFE-4/RV-1
Issue 2.0 Mar/2005 Copyright © 2005 Nokia Corporation Page 2-7
Company Confidential
C602 Top L 5 Chipcap ±0.25pF NP0 3p9 50V normal,-0.25pF, 0.25pF 0402C
C603 Top M 6 Chipcap X7R 1n0 50V normal,-10%,10% 0402C
C605 Top M 5 CHIPCAP X5R 100n 10V normal,-10%,10% 0402C
C606 Top J 8 Chipcap 5% NP0 27p 50V normal,-5%,5% 0402C
C607 Top L 6 CHIPCAP X5R 3u3 6V3 normal,-10%,10% 0805C_H1.35
C610 Top L 9 CHIPCAP X5R 100n 10V normal,-10%,10% 0402C
C615 Top I 8 Chipcap X7R 10n 16V normal,-10%,10% 0402C
C620 Top H 8 Chipcap 5% NP0 27p 50V normal,-5%,5% 0402C
C622 Top J 5 CHIPCAP X5R 100n 10V normal,-10%,10% 0402C
C623 Top K 6 CHIPCAP X5R 100n 10V normal,-10%,10% 0402C
C624 Top J 6 Chipcap 5% NP0 27p 50V normal,-5%,5% 0402C
C625 Top K 6 CHIPCAP X5R 1u0 10V normal,-10%,10% 0603C_H0.95
C626 Top J 6 Chipcap +-0.25pF NP0 5p6 50V normal,-0.25pF, 0.25pF 0402C
C627 Top K 5 CHIPCAP X5R 10u 6.3V normal,-10%,10% 1206C_H1.8
C628 Top J 7 Chipcap X7R 10n 16V normal,-10%,10% 0402C
C629 Top J 6 Chipcap 5% NP0 27p 50V normal,-5%,5% 0402C
C631 Top H 6 CHIPCAP NP0 0p5 50V normal, -0.25p, 0.25p 0402C
C632 Top I 8 Chipcap X7R 1n0 50V normal,-10%,10% 0402C
C633 Top J 6 Chipcap 5% NP0 27p 50V normal,-5%,5% 0402C
C634 Top H 7 Chipcap +-0.25pF NP0 2p2 50V normal,-0.25pF, 0.25pF 0402C
C635 Top J 7 Chipcap 5% NP0 27p 50V normal,-5%,5% 0402C
C636 Top J 8 Chipcap X7R 10n 16V normal,-10%,10% 0402C
C639 Top C 5 Chipcap 5% NP0 47p 50V normal,-5%,5% 0402C
C701 Top B 5 Chipcap 5% NP0 15p 50V normal,-5%,5% 0402C
C703 Top B 3 Chipcap X7R 1n0 50V normal,-10%,10% 0402C
C704 Top K 7 Chipcap 5% NP0 27p 50V normal,-5%,5% 0402C
C705 Top K 8 Chipcap 5% NP0 15p 50V normal,-5%,5% 0402C
C706 Top J 6 Chipcap 5% NP0 68p 50V normal,-5%,5% 0402C
C707 Top J 6 CHIPCAP NP0 2n2 16V normal,-5%,5% 0603C
C709 Top M 7 CHIPCAP NP0 180p 25V normal,-5%,5% 0402C
C710 Top J 6 CHIPCAP NP0 180p 25V normal,-5%,5% 0402C
C711 Top L 7 CHIPCAP NP0 3n9 25V normal,-5%,5% 0805C_AVX
C712 Top M 7 CHIPCAP NP0 180p 25V normal,-5%,5% 0402C
C715 Top L 6 Chipcap 5% NP0 68p 50V normal,-5%,5% 0402C
C716 Top L 6 Chipcap 5% NP0 68p 50V normal,-5%,5% 0402C
C717 Top L 6 Chipcap 5% NP0 27p 50V normal,-5%,5% 0402C
C718 Top L 6 Chipcap X7R 1n0 50V normal,-10%,10% 0402C
C721 Top H 5 Chipcap X7R 1n0 50V normal,-10%,10% 0402C
C722 Top H 5 Chipcap 5% NP0 15p 50V normal,-5%,5% 0402C
C731 Top I 5 Chipcap 5% NP0 27p 50V normal,-5%,5% 0402C
Item
Location
Side, Grid ref
Description and value Type
