Nokia 616 Service Manual

TFE-4/RV-1 Company Confidential
2 - Parts List Nokia Customer Care
Page 2-8 Copyright © 2005 Nokia Corporation Issue 2.0 Mar/2005
Company Confidential
C733 Top I 5 Chipcap 5% NP0 27p 50V normal,-5%,5% 0402C
C734 Top I 5 Chipcap 5% NP0 27p 50V normal,-5%,5% 0402C
C740 Top K 8 CHIPCAP X5R 3u3 6V3 normal,-10%,10% 0805C_H1.35
C741 Top M 9 Chipcap +-0.25pF NP0 5p6 50V normal,-0.25pF, 0.25pF 0402C
C803 Top D 3 Chipcap 5% NP0 27p 50V normal,-5%,5% 0402C
C804 Top D 3 Chipcap 5% NP0 27p 50V normal,-5%,5% 0402C
C805 Top J 5 Chipcap 5% NP0 27p 50V normal,-5%,5% 0402C
C807 Top D 6 Chipcap 5% NP0 27p 50V normal,-5%,5% 0402C
C812 Top D 6 CHIPCAP X5R 1u0 10V normal,-10%,10% 0603C_H0.95
C813 Top E 4 Chipcap 5% NP0 27p 50V normal,-5%,5% 0402C
C815 Top C 6 CHIPTCAP 33U M 16V 6.0X3.2X1.5 33u 16V normal,-20%,20% TANT_TPSW2
C816 Top F 3 Chipcap 5% NP0 27p 50V normal,-5%,5% 0402C
C818 Top H 5 Chipcap 5% NP0 27p 50V normal,-5%,5% 0402C
C820 Top G 4 Chipcap 5% NP0 27p 50V normal,-5%,5% 0402C
C821 Top G 5 Chipcap +-0.25pF NP0 1p8 50V normal,-0.25pF,0.25pF 0402C
C822 Top H 5 Chipcap 5% NP0 27p 50V normal,-5%,5% 0402C
C823 Top C 5 CHIPCAP NP0 1p0 50V normal,-0.1p,0.1p 0402C
C824 Top H 5 Chipcap +-0.25pF NP0 3p9 50V normal,-0.25pF,0.25pF 0402C
C825 Top E 3 CHIPCAP X5R 100n 10V normal,-10%,10% 0402C
C826 Top C 5 Chipcap +-0.25pF NP0 8p2 50V normal,-0.25pF,0.25pF 0402C
C871 Top I 8 Chipcap 5% NP0 27p 50V normal,-5%,5% 0402C
D200 Top O 4 UEM V4.4 W-DOG ENA TO09H
TFBGA168
~~~ uBGA168
D400 Top R 7 UPP8M V1.1 F741987A C05
UBGA144
~ ~ ~ uBGA144_CC
D450 Top U 7 FLASH 4MX16 1V8/1V8 VTFBGA44 4Mx16 ~ ~ uBGA40_64MB_4
G701 Top L 8 VCO 3420-3980MHZ 2.7V 19MA 3420-3980MHz ~ ~ VCO_FDK_IT_H1.7
L132 Top N 2 FERRITE BEAD 0R5 600R/100MHz ~ ~ 0603_BLM
L133 Top N 2 FERRITE BEAD 0R5 600R/100MHz ~ ~ 0603_BLM
L150 Top V 3 CHIP BEAD ARRAY 2x1000R/
100MHz
~ - 0405_2_MATSU
L168 Top V 2 CHIP BEAD ARRAY 2x1000R/
100MHz
~ - 0405_2_MATSU
L260 Top Q 2 FERRITE BEAD 0R5 600R/100MHz ~ ~ 0603_BLM
L261 Top Q 2 FERRITE BEAD 0R5 600R/100MHz ~ ~ 0603_BLM
L262 Top R 2 FERRITE BEAD 0R5 600R/100MHz ~ ~ 0603_BLM
L263 Top R 2 FERRITE BEAD 0R5 600R/100MHz ~ ~ 0603_BLM
L264 Top Q 2 FERRITE BEAD 0R5 600R/100MHz ~ ~ 0603_BLM
L265 Top R 2 FERRITE BEAD 0R5 600R/100MHz ~ ~ 0603_BLM
L603 Top H 6 CHIP COIL 3N9 +-0N3 Q28/800M 3n9H ~ normal,-0n3,+0n3 0402L
L604 Top H 6 CHIP COIL 3N9 +-0N3 Q28/800M 3n9H ~ normal,-0n3,+0n3 0402L
Item
Location
Side, Grid ref
Description and value Type
