Nokia 616 Service Manual

Nokia Customer Care 2 - Parts List
Company Confidential TFE-4/RV-1
Issue 2.0 Mar/2005 Copyright © 2005 Nokia Corporation Page 2-9
Company Confidential
L606 Top H 7 CHIP COIL 8N2 J Q28/800MHZ 8n2H ~ normal,-5%,+5% 0402L
L607 Top H 7 CHIP COIL 8N2 J Q28/800MHZ 8n2H ~ normal,-5%,+5% 0402L
L608 Top B 5 CHIP COIL 33N J Q7/100MHZ 33nH ~ normal,-5%,+5% 0402_ELJRF
L701 Top K 7 CHIP COIL 33N J Q7/100MHZ 33nH ~ normal,-5%,+5% 0402_ELJRF
L702 Top K 8 CHIP COIL 33N J Q7/100MHZ 33nH ~ normal,-5%,+5% 0402_ELJRF
L703 Top K 7 CHIP COIL 33N J Q7/100MHZ 33nH ~ normal,-5%,+5% 0402_ELJRF
L705 Top H 6 CHIP COIL 3N3 +-0N3 Q28/800M 3n3H ~ normal,-0n3,+0n3% 0402L
L706 Top I 6 CHIP COIL 15N J Q30/800M 15nH ~ normal,-5%,5% 0402L
L707 Top I 6 CHIP COIL 18N J Q29/800M 18nH ~ normal,-5%,5% 0402L
L708 Top I 6 CHIP COIL 18N J Q29/800M 18nH ~ normal,-5%,5% 0402L
L710 Top G 6 CHIP COIL 10N J Q30/800M 10nH ~ normal,-5%,5% 0402L
L711 Top I 5 CHIP COIL 15N J Q30/800M 15nH ~ normal,-5%,5% 0402L
L712 Top G 5 CHIP COIL 3N9 +-0N3 Q28/800M 3n9H ~ normal,-0n3,+0n3 0402L
L801 Top C 4 DIR.COUP 897.5/1747.5/1880MHZ 897.5/1747.5/
1880M
~ ~ COUPLER_LDC15D
L805 Top E 3 FERRITE BEAD 42R/100MHZ 42R/100MHz ~ ~ 0805_FERRITE
L806 Top G 5 CHIP COIL 10N J Q30/800M 10nH ~ normal,-5%,5% 0402L
L807 Top H 5 CHIP COIL 5N6 +-0N3 Q28/800M 5n6H ~ normal,-0n3,+0n3 0402L
L808 Top C 5 CHIP COIL 5N6 +-0N3 Q28/800M 5n6H ~ normal,-0n3,+0n3 0402L
N601 Top I 7 MJOELNER RF ASIC S2006 LFBGA80 ~ ~ ~ LFBGA_80
N801 Top E 5 PW AMP PF08125B GSM900/1800/
1900
~ ~ ~ PW_AMP_PA_HDE1
3A
R100 Top T 5 RES NETWORK 0W06 2x47R ~ normal,-5%,5% 0404_R_SR
R101 Top Y 3 RES NETWORK 0W06 2x47R ~ normal,-5%,5% 0404_R_SR
R102 Top X 3 Resistor 5% 63mW 220k ~ normal,-5%,5% 0402R
R103 Top T 5 CHIP VARISTOR VWM14V VC50V 14V/50V ~ - 0402_VAR
R104 Top X 3 RES NETWORK 0W06 2x47R ~ normal,-5%,5% 0404_R_SR
R105 Top W 5 RES NETWORK 0W06 2x47R ~ normal,-5%,5% 0404_R_SR
R106 Top W 6 RES NETWORK 0W06 2x47R ~ normal,-5%,5% 0404_R_SR
R107 Top W 7 RES NETWORK 0W06 2x47R ~ normal,-5%,5% 0404_R_SR
R108 Top W 7 RES NETWORK 0W06 2x47R ~ normal,-5%,5% 0404_R_SR
R109 Top Y 7 RES NETWORK 0W06 2x47R ~ normal,-5%,5% 0404_R_SR
R110 Top Y 6 RES NETWORK 0W06 2x47R ~ normal,-5%,5% 0404_R_SR
R111 Top Y 5 RES NETWORK 0W06 2x47R ~ normal,-5%,5% 0404_R_SR
R112 Top Y 4 RES NETWORK 0W06 2x47R ~ normal,-5%,5% 0404_R_SR
R114 Top T 3 Resistor 5% 63mW 27k ~ normal,-5%,5% 0402R
R115 Top T 3 Resistor 5% 63mW 47k ~ normal,-5%,5% 0402R
R132 Top N 7 Chipres 0W06 jumper 0R ~ normal,-,- 0402R
R151 Top U 3 RES NETWORK 0W06 2x1k0 ~ normal,-5%,5% 0404_R_SR
R152 Top U 2 RES NETWORK 0W06 2x1k0 ~ normal,-5%,5% 0404_R_SR
Item
Location
Side, Grid ref
Description and value Type
