Nokia 616 Service Manual

TFE-4/RV-1 Company Confidential
2 - Parts List Nokia Customer Care
Page 2-10 Copyright © 2005 Nokia Corporation Issue 2.0 Mar/2005
Company Confidential
R154 Top Q 3 Resistor 5% 63mW 10k ~ normal,-5%,5% 0402R
R165 Top Q 4 Resistor 5% 63mW 47k ~ normal,-5%,5% 0402R
R166 Top T 4 Resistor 5% 63mW 10k ~ normal,-5%,5% 0402R
R167 Top U 3 RES NETWORK 0W06 2x1k0 10V normal,-20%,20% 0404_R_SR
R182 Top U 4 RES NETWORK 0W06 2x47R ~ normal,-5%,5% 0404_R_SR
R200 Top Q 5 CHIPRES 0W5 0R22 J 1210 0R22 ~ normal,-5%,5% 1210_R
R202 Top N 3 RES NETWORK 0W03 4X100K J 0804 4x100k ~ ~ EXB28V
R220 Top N 3 Resistor 5% 63mW 4k7 ~ normal,-5%,5% 0402R
R240 Top N 3 Resistor 5% 63mW 4k7 ~ normal,-5%,5% 0402R
R305 Top N 3 Resistor 5% 63mW 100k ~ normal,-5%,5% 0402R
R306 Top P 7 RES NETWORK 0W06 2x47R ~ normal,-5%,5% 0404_R_SR
R307 Top P 8 RES NETWORK 0W06 2x47R ~ normal,-5%,5% 0404_R_SR
R308 Top F 1 RES NETWORK 0W06 2x47R ~ normal,-5%,5% 0404_R_SR
R309 Top F 8 RES NETWORK 0W06 2x47R ~ normal,-5%,5% 0404_R_SR
R310 Top P 8 RES NETWORK 0W06 2x47R ~ normal,-5%,5% 0404_R_SR
R311 Top P 8 RES NETWORK 0W06 2x47R ~ normal,-5%,5% 0404_R_SR
R312 Top G 1 RES NETWORK 0W06 2x47R ~ normal,-5%,5% 0404_R_SR
R313 Top G 8 RES NETWORK 0W06 2x47R ~ normal,-5%,5% 0404_R_SR
R314 Top P 4 Resistor 5% 63mW 220k ~ normal,-5%,5% 0402R
R386 Top P 4 Resistor 5% 63mW 100R ~ normal,-5%,5% 0402R
R387 Top Q 4 CHIP VARISTOR VW14V VC50V 14V/50V ~ - 0402_VAR
R388 Top S 4 ASIP EMIF03-SIM01 SIM FILTER
BGA8
~~~ uBGA8
R390 Top P 4 Resistor 5% 63mW 100k ~ normal,-5%,5% 0402R
R420 Top L 5 Resistor 5% 63mW 100R ~ normal,-5%,5% 0402R
R422 Top N 6 Resistor 5% 63mW 27k ~ normal,-5%,5% 0402R
R424 Top O 9 Resistor 5% 63mW 220k ~ normal,-5%,5% 0402R
R450 Top S 5 Resistor 5% 63mW 4k7 ~ normal,-5%,5% 0402R
R483 Top W 5 Resistor 5% 63mW 10k ~ normal,-5%,5% 0402R
R484 Top W 5 Resistor 5% 63mW 10k ~ normal,-5%,5% 0402R
R485 Top V 5 Resistor 5% 63mW 10k ~ normal,-5%,5% 0402R
R486 Top W 3 Resistor 5% 63mW 10k ~ normal,-5%,5% 0402R
R487 Top W 2 Resistor 5% 63mW 10k ~ normal,-5%,5% 0402R
R488 Top W 2 Resistor 5% 63mW 10k ~ normal,-5%,5% 0402R
R601 Top L 5 Resistor 5% 63mW 1k5 ~ normal,-5%,5% 0402R
R602 Top L 5 Resistor 5% 63mW 33k ~ normal,-5%,5% 0402R
R603 Top L 5 Resistor 5% 63mW 15k ~ normal,-5%,5% 0402R
R610 Top M 5 Resistor 5% 63mW 10R ~ normal,-5%,5% 0402R
R612 Top I 8 Resistor 5% 63mW 1k0 ~ normal,-5%,5% 0402R
R617 Top J 8 Resistor 5% 63mW 22R ~ normal,-5%,5% 0402R
Item
Location
Side, Grid ref
Description and value Type
