Nokia 616 Service Manual

Nokia Customer Care 2 - Parts List
Company Confidential TFE-4/RV-1
Issue 2.0 Mar/2005 Copyright © 2005 Nokia Corporation Page 2-11
Company Confidential
R618 Top L 5 Resistor 5% 63mW 560R ~ normal,-5%,5% 0402R
R623 Top J 6 Resistor 5% 63mW 100R ~ normal,-5%,5% 0402R
R625 Top J 6 Resistor 5% 63mW 47R ~ normal,-5%,5% 0402R
R626 Top J 8 Resistor 1% 63mW 2k7 ~ normal,-1%,1% 0402R
R629 Top J 7 Chipres 0W06 5R6 J 5R6 ~ normal,-5%,5% 0402R
R630 Top J 7 Resistor 5% 63mW 330R ~ normal,-5%,5% 0402R
R706 Top J 6 Resistor 5% 63mW 33k ~ normal,-5%,5% 0402R
R707 Top J 5 Resistor 5% 63mW 15k ~ normal,-5%,5% 0402R
R708 Top J 5 Resistor 5% 63mW 4k7 ~ normal,-5%,5% 0402R
R710 Top L 7 CHIPRES 0W06 5K6 F 5k6 ~ normal,-1%,1% 0402R
R711 Top L 7 Resistor 5% 63mW 8k2 ~ normal,-5%,5% 0402R
R713 Top L 6 RES NETWORK 0W06 4x5.6k ~ normal,-5%,5% MNR04
R717 Top L 6 RES NETWORK 0W06 2x2k2 ~ normal,-5%,5% MNR02_SR
R720 Top H 6 Resistor 5% 63mW 82R ~ normal,-5%,5% 0402R
R721 Top H 6 Resistor 5% 63mW 82R ~ normal,-5%,5% 0402R
R725 Top I 6 Resistor 5% 63mW 120R ~ normal,-5%,5% 0402R
R726 Top I 6 Resistor 5% 63mW 120R ~ normal,-5%,5% 0402R
R730 Top L 9 Chipres 0W06 5R6 J 0402 5R6 ~ normal,-5%,5% 0402R
R731 Top K 8 RES NETWORK 0W04 3DB ATT 292R/17R6/
292R
~ ~ 0404_RAC10
R801 Top D 4 Resistor 5% 63mW 4k7 ~ normal,-5%,5% 0402R
R802 Top J 5 Resistor 5% 63mW 100R ~ normal,-5%,5% 0402R
R803 Top C 4 Resistor 5% 63mW 47R ~ normal,-5%,5% 0402R
R805 Top F 4 RES NETWORK 0W04 5DB ATT 178R5/30R4/
178R5
~ ~ 0404_RAC10
R806 Top H 5 RES NETWORK 0W04 3DB ATT 292R/17R6/
292R
~ ~ 0404_RAC10
R817 Top G 5 Resistor 5% 63mW 1k0 ~ normal,-5%,5% 0402R
R818 Top G 4 Resistor 5% 63mW 100R ~ normal,-5%,5% 0402R
R819 Top F 6 RES NETWORK 0W04 3DB ATT 292R/17R6/
292R
~ ~ 0404_RAC10
R820 Top G 5 Resistor 5% 63mW 1k0 ~ normal,-5%,5% 0402R
R821 Top G 5 Resistor 5% 63mW 100R ~ normal,-5%,5% 0402R
R822 Top H 5 Resistor 5% 63mW 3k9 ~ normal,-5%,5% 0402R
R823 Top H 5 Resistor 5% 63mW 180R ~ normal,-5%,5% 0402R
T701 Top H 6 TRANSF BALUN 1800+-100MHZ
2X1.25
~ ~ ~ TRANS_LDB213
T702 Top K 7 BALUN TRANS 3.7GHZ+/-300MHZ
0805
~~~ TRANS_LDB15
V100 Top Y 4 ZDIX4 TVS/ESD RSA6.1EN 6V1
SOT353
~ ~ ~ SOT323_5L
Item
Location
Side, Grid ref
Description and value Type
