Nokia 616 Service Manual

Nokia Customer Care 4 - Service Tools
Company Confidential TFE-4/RV-1
Issue 2.0 Mar/2005 Copyright © 2005 Nokia Corporation Page 4-11
Company Confidential
Audio Connector
The Audio Connector J3 and J4 have following pinning.
Note: Pin 1 is at the left side of the PWB connector (Face view).
A K2 coded connector is used
Switches on MJ-1
Pin No Signal (J3) Pin No Signal (J4)
2 B2BXEARN 2 B2BXEARN
3 B2BXEARP 3 B2BXEARP
4 B2BHFMICN 4 B2BHFMICN
5 B2BHFMICP 5 B2BHFMICP
9gnd 9gnd
J4 J5 J6
SIM
holde
r
Testpoints
S2=Power S3=Ignition
S4=SIM Switch
On
Off
On
Of
f
N
orma
l
Flash
HDLOOPHFLOOP
Power
connector
