Boot Options
142
Basic System Configuration Guide
3HE 11010 AAAC TQZZA Edition: 01
Table 18 describes the keywords used in ADP instructions. A DHCP offer message
can contain a maximum of 15 instructions in either the Bootfile Name option, or in an
external file referenced by the include keyword. If more than 15 instructions are
included, ADP fails to complete and the system generates an error message in the
ADP log.
5.1.2.4 Test and Commit
In order for ADP to be declared successful during the test and commit stage, the
discovered configuration must contain an IP address. If the optional test-ip keyword
is included in the ADP instructions, the node pings the IP address included in the
DHCP OFFER message. If ADP is successful, the system stores the configuration
and opens an SSH session to provide remote operators access to the router.
ADP can be controlled, without a connected PC or ASCII terminal, by the ACO/LT
button on the Fan module. You can use the ACO/LT button to terminate or restart
ADP, or reboot the chassis.
Table 18 ADP Instructions
Keyword Description Format
sys-addr Specifies the system interface IP address
and the system base routing instance
subnet
sys-addr 10.10.10.1/32
sys-name Specifies the chassis name sys-name SITE43_7705
sys-loc Specifies the chassis location sys-loc 600_MARCH_ROAD
load-cfg Specifies the URL of a template
configuration file to load into the router's
runtime configuration
load-cfg ftp://.....@.../7705.cfg
test-ip Specifies an IP address that must be
successfully pinged before committing
configuration and declaring ADP a
success
test-ip 100.20.2.30
include Specifies the URL of a file containing
additional ADP instructions
include ftp://.....@.../7705.tmp
Any BOF
keyword
Interpreted as instructions to update the
specified field in the BOF
As per BOF
