Basic System Configuration Guide System Management
Edition: 01 3HE 11010 AAAC TQZZA 439
Table 45 Show System PTP Clock CSM Output Fields
Label Description
Local Clock
Clock Type The local PTP clock type, one of: ordinary master, ordinary slave,
boundary, or transparent-e2e
PTP Profile The PTP profile, as configured by the profile command, one of:
ieee-1588, itu-telecom-freq, or g8275dot1-2014
Domain The PTP device domain
Network Type Indicates whether SONET or SDH values are being used for
encoding synchronous status messages
Admin State up – the local PTP clock is administratively enabled
down – the local clock is administratively shut down and not
running
Oper State Up – the local clock is operationally enabled and running
Down – the local clock is operationally disabled and not running
Announce Interval The message interval used for announce messages
Announce Rx
Timeout
The number of announce timeouts that need to occur on a PTP
slave port or boundary clock port in slave mode before
communication messages with a master clock are deemed lost
and the master clock is considered not available
Clock Id A unique 64-bit number assigned to the clock
Clock Class The local clock class
Clock Accuracy The local clock accuracy designation
Clock Variance The local clock variance
Clock Priority1 The first priority value of the local clock, used by the Best Master
Clock Algorithm (BMCA) to determine which clock should provide
timing for the network
Clock Priority2 The second priority value of the local clock. This value is used by
the BMCA to determine which clock should provide timing for the
network.
PTP Port State The PTP port state, one of: disabled, listening, slave, master,
passive, or faulty
Last Changed The time the PTP port state last changed
