ACCESS GATEWAY

Introduction 34

Notes, Cautions, and Warnings

The following formats are used throughout this User Guide:

General notes and additional information that may be useful are indicated with a Note.

Cautions and warnings are indicated with a Caution. Cautions and warnings

provide important information to eliminate the risk of a system malfunction or

possible damage.
