Installing the Access Gateway 61

Archiving Your Configuration Settings

Once you have installed your Access Gateway and established the configuration settings, you should write the

settings to an archive file. If you ever experience problems with the system, your archived settings can be

restored at any time.

Refer to the following procedures:



Exporting Configuration Settings to the Archive File {Export}” on page 194.



Importing Configuration Settings from the Archive File {Import}” on page 197.
