60 Installing the Access Gateway

Enter UDP DNS Redirection Port [1029 ]:

Enter Proxy UDP DNS Port [1028 ]:

Enable/Disable DNSSEC [enabled ]:

Host Name usg

DNS Redirection Port Mode fixed

UDP DNS Redirection Port 1029

Proxy UDP DNS Port 1028

DNSSEC Support enabled
