ACCESS GATEWAY

66 System Administration

Logging In

To access the Access Gateway’s Web Management Interface, use the Manager or Operator login user name

and password you defined during the installation process (refer to Assigning Login User Names and

Passwords).

User names and passwords are case-sensitive.
