ACCESS GATEWAY

46 Installing the Access Gateway

DHCP Parameter Your Settings Default Values

DHCP Server Subnet Mask 255.255.255.0

DHCP Pool Start IP Address 10.0.0.12

DHCP Pool End IP Address 10.0.0.72

DHCP Lease Minutes 1440

An example of a basic network including an AG is shown below.
