RECIPE 1 24−11−03 TEXT 1
RECIPE 2 06−12−03 TEXT 2
File: Description:
Recipes
RECIPE 3
Operation
4-49
P/N 7105144G
2008 Nordson Corporation
VersaBlue_NW
Recipes
A recipe is a file in which the customer saves his production-specific
parameters.
Save recipe
The operator must enter a name (max. 8 characters) under File. To better
identify the individual recipes, information such as the name of the
application can be entered under Description. All current, adjustable
parameters are saved, except for the following.
Fig. 4-54
Exceptions:
Brightness and contrast
Date / time
Local language
IPC IP address and subnet mask
PROFIBUS address
Passwords
Selected line speed signal and all values based on the line speed signal
NOTE: Up to 500 recipes can be saved.
Load recipe
The current parameters are overwritten with the values from the selected
recipe.
NOTE: If during loading of the recipe (approx. 4 s) the melter is switched off
(e.g. power failure), the control unit will no longer function properly. The
desired recipe must then be loaded again.
Recipe is irrevocably deleted.
Sort recipes by name, description or date.
