Description of Symbols
The following symbols appear on several screens and indicate
Call up a help text
General information
Detailed information
Return to previous level. Cancel and close when in input windows
To next/previous screen
Confirmation, acceptance of a value
Backspace, delete
Page up/down
Increase/decrease value
Setup
Standard Symbols of Temperature Channels
Grid (low melt)
Reservoir (high melt)
Hose
Gun
Air heater
