Operation
4-37
P/N 7105144G
2008 Nordson Corporation
VersaBlue_NW
Switching On/Off Heaters
The heaters can be switched on via the control panel, the Standard I/O
interface, the seven-day-clock or the field bus. The main switch must be set
to I/ON.
The main contactor closes. The power supply to heaters and motors is
switched on. The heatup phase begins.
NOTE: When the heaters have been switched off, the control unit continues
to be supplied with voltage, so the heaters can be switched on at any time
via the seven-day clock.
Switching On/Off Seven-day Clock
Refer to Control Panel − Overview − / V8
Activate Password Protection
The password protection (selected security level) is active immediately; if
this key is not touched, it is activated after 10 minutes.
Refer to Control Panel − Overview − / V19.
NOTE: This key is visible only when a password has been entered.
