Start filling
Stop filling
Tank overfilled
Tank level low
Tank empty
Filling
Screen
cleaning
System ready setup
Select temperature/
pressure units
Password setup
Profibus setup
Temperature unit:
°C
Pressure unit:
bar
Operation
4-51
P/N 7105144G
2008 Nordson Corporation
VersaBlue_NW
Level Control (Fixed Measuring Points)
The level sensor measures the presence of material at five different points.
If the melter is heated up and there are no undertemperature faults or
sensor alarms (short-circuit / sensor break), the command to fill is given as
soon as the level falls below the measuring point Start filling.
Filling continues until the measuring point Stop filling is reached.
The status diode Filling is illuminated during filling.
Fig. 4-56 V13
Filling, the warning Tank level low and the fault Tank empty can only be
triggered when the heaters are switched on. Filling stops when sensor
alarms occur or the main contactor or level control is switched off.
Level control is activated
Level control is deactivated.
Level display and monitoring no longer occur. Filling, the warning Tank level
low and the fault Tank empty are no longer triggered.
Now the tank can be emptied for maintenance or repair work without the
fault Tank empty occurring.
Screen 2: Units, Ready Delay Time, Password, Service
Interval, Field Bus
Touch the key to move to the second setup screen. In this screen the
units can be changed, the maximum temperature setpoint, ready delay time,
password and service interval can be entered, and the type of field bus can
be selected.
Additional features: Change screen contrast and clean screen.
Fig. 4-57 V14
Select Temperature/Pressure Units
Either °C or °F can be selected as the temperature unit.
°C
Either bar, psi or kPa can be selected as the pressure unit.
bar
Fig. 4-58 V15
