Operation
4-20
P/N 7105144G
2008 Nordson Corporation
VersaBlue_NW
Recommended Temperature Setpoints
The temperature setting is determined, among other things, by the
processing temperature prescribed by the material supplier.
CAUTION: Nordson will grant no warranty and assume no liability for
damage resulting from incorrect temperature settings.
Grid (low melt)
Up to 20 °C (36 °F) below prescribed processing temperature
Reservoir (high melt) Prescribed processing temperature
(Material quantity used <50 g/min: 0 to 10 °C (18 °F) below prescribed
processing temperature
Undertemperature value
(warning)
10 °C (18 °F) below set processing temperature
Air heater: approx. 10 °C (18 °F) below set processing temperature
Undertemperature value
(fault)
15 °C (27 °F) below set processing temperature
Air heater: approx. 20 °C (36 °F) below set processing temperature
Overtemperature value
(warning)
10 °C (18 °F) above set processing temperature
Air heater: approx. 10 °C (18 °F) above set processing temperature
Overtemperature value (fault)
15 °C (27 °F) above set processing temperature
Air heater: approx. 20 °C (36 °F) above set processing temperature
Filling valve (option) Prescribed processing temperature*
Gun (accessory) Prescribed processing temperature(s)*
Hose (accessory) Prescribed processing temperature*
* CAUTION: The maximum operating temperature of the installed gun and the other heated components
should be considered when setting temperatures on the melter control panel.
Refer to Control Panel – Overview − / T1 for information on input.
