12.1 INTRODUCTION
When the machine is turned on, the software
release "A" is displayed as well ad the position
of the 4 dip switches for configuring the machine
"B". When the number is displayed the related
dipswich is position ON.
The programming keys are:
1
ENTER key: to go into the menu and/
or to confirm the value set.
2-3
- Up and down arrow keys:
To scroll through the menu and increase or
decrease the valves.
4
RESET key: to return to the previous
step.
The others keys are numbered from 1 to 7 as in
a picture:
1 Espresso
2 2 Espresso
3 Coffee
4 Cappuccino
5 Macchiato
6 Caffellatte
7 Milk
Note: button 7 could be programmed only if
dip switch 3 is set to ON (see chapter
13.8), and the only available program is
Milk.
If dip switch 3 is set to OFF button 7 is
not programmable and it works like a
pulse.
Edition 02 to 02/2014
12.3
SERVICE MANUAL
A
B
Fig. 269
00:05
2
3
14
Fig. 270
00:32
1
2
3
7
4
5
6
Fig. 271
00:28
