Nuova Simonelli PRONTOBAR - Removing Solenoid Valves

7.2 REMOVING THE SOLENOID
VALVE
This must be done with the machine switched off
and the boiler cold.
To access the service engineer must:
1 Remove the right panel.
2 Remove the condenser exhaust pipe clip
and pipe (for frother solenoid valve only; all
other solenoids valves are 2 way valves).
3 Remove the coil's two power wires.
4 Remove the clip of the pipe that carries
steam to the frother.
5 Remove the pipe.
Edition 02 to 02/2014
7.4
SERVICE MANUAL
1
Fig. 168
00:58
3
Fig. 170
01:09
2
Fig. 169
01:03
5
4
Fig. 171
01:16
