1.4 TRANSPORT AND
HANDLING
1.4.1 MACHINE IDENTIFICATION
Always quote the machine serial number in all
communications to the manufacturer, Nuova
Simonelli.
Fig. 12
1.4.2 TRANSPORT
The machine is transported on pallets which also
contain other machines - all boxed and secured
to the pallet with supports.
Prior to carrying out any transport or handling
operation, the operator must:
t QVUPOXPSLHMPWFTBOEQSPUFDUJWFGPPU-
wear, as well as a set of overalls which
must be elasticated at the wrists and
ankles.
The pallet must be transported using a
suitable means for lifting (e.g., forklift).
1.4.3 HANDLING
CAUTION
RISK OF IMPACT OR CRASHING
During all handling operations, the operator must
ensure that there are no persons, objects or
property in the handling area.
The pallet must be slowly raised to a height of 30
cm (11,8 in) and moved to the loading area.
After first ensuring that there are no persons,
objects or property, loading operations can be
carried out.
Upon arrival at the destination and after ensuring
that there are no persons, objects or property in
the unloading area, the proper lifting equipment
(e.g. forklift) should be used to lower the pallet to
the ground and then to move it (at approx. 30 cm
(11,8 in) from ground level), to the storage area.
CAUTION
RISK OF IMPACT OR CRASHING
Before carrying out the following operation, the
load must be checked to ensure that it is in the
correct position and that, when the supports are
cut, it will not fall.
The operator, who must first put on work gloves
and protective footwear, will proceed to cut the
supports and to storing the product. To carry out
this operation, the technical characteristics of the
product must be consulted in order to know the
weight of the machine and to store it accordingly.
CAUTION
RISK OF POLLUTION
Fig. 13
Edition 02 to 02/2014
1.8
SERVICE MANUAL
