2.1.5 OPTIONAL DIRECT GROUNDS
DISCHARGE
1 Grounds discharge version, the service engi-
neer must insert the conveyor funnel into
the drawer and the discharge pipe into the
relevant fitting under the machine.
2.1.6 REFILL COFFEE BOILER
To prevent any damage, the first time that the
machine is installed or whenever the coffee boiler
is empty it’s necessary to manually fill the boiler.
Once that all the previous connections and fits
are complete, the machine can be connected to
the power supply.
To fill manually the coffee boiler hold press the up
and down arrows and switch on the main switch
on the bottom left side to enter in the “Manual
Movement” function.
Hold press hot water key until water comes out
from the hot water wand.
2.1.7 LUBRICATION
WARNING
If the machine is produced more then 3 month
before the installation date, group lubrication
is needed.
1 Enter in manual movement: switch off the
machine and hold pressed the arrows up
and down while switching on the machine
with the main switch. Release the two but-
tons when the display shows “MANUAL
MOVEMENT”.
Edition 02 to 02/2014
2.5
SERVICE MANUAL
1
Fig. 23
00:34
Fig. 24
Fig. 25
