Nuova Simonelli PRONTOBAR - Infusion Chamber Removal

10 Lubricate the bearings and bushing with
NUOVA SIMONELLI silicon lubricant.
3.5 INFUSION
CHAMBER REMOVAL
The brewing chamber can be reached by remov-
ing the group, the motor and the worm screw:
1 Pull out the two runners by removing two 3
mm allen screws and the two 2.5 mm on the
worm screw cover.
2 The nut is at the back of the infusion cham-
ber. To remove, undo the four screws in the
group’s lower support.
Edition 02 to 02/2014
3.8
SERVICE MANUAL
1
Fig. 71
03:19
2
2
2
2
Fig. 72
03:22
Fig. 73
03:30
Fig. 70
