Nuova Simonelli PRONTOBAR - Keyboard Description (Standard Configuration); Keyboard Description

KEY
1 Product’s dose key
2 Programming keys
3 Hot water key
4 Steam key
5 Decaffeinated coffee
key
6 ON/OFF
key
7 Washing
key
8 Left grinder
key
9 Milk
button
Edition 02 to 02/2014
1.3
SERVICE MANUAL
1.2 KEYBOARD DESCRIPTION (Standard configuration)
