7.3 COFFEE SOLENOID VALVE
To replace the coffee solenoid valve:
1 Remove the front panel by loosing the 4
screws.
2 Remove the Teflon pipe by holding the ring.
3 Remove the exhaust pipe clip and the coffee
solenoid exhaust pipe.
4 Pull out the two electrical connection wires.
Edition 02 to 02/2014
7.6
SERVICE MANUAL
1
Fig. 175
01:44
Fig. 176
4
Fig. 178
01:52
3
Fig. 177
01:47
