6 With a 13 wrench, turn the nut and remove
the copper steam pipe.
7 With a Phillips screwdriver, undo the two
screws that hold the solenoid.
8 When replacing the solenoid, ensure proper
positioning of the joints.
Edition 02 to 02/2014
7.5
SERVICE MANUAL
6
Fig. 172
01:21
OUT
IN
Fig. 174
01:35
7
7
Fig. 173
01:28
