Nuova Simonelli PRONTOBAR - Water Tank Version

2 Drill the drainage tray to match the collector.
3 Clamp the drainage pipe to the drainage col-
lector.
2.1.4 WATER TANK VERSION
1 Fill the tank with demineralised water to the
maximum level.
WARNING
The water hardness must be less then 4° - 6°
fr (french degree). Otherwise the conditions of
guarantee of the machine will expire.
Edition 02 to 02/2014
2.4
SERVICE MANUAL
1
MAX
LEVEL
MAX
LEVEL
Fig. 22
00:25
Fig. 20
3
Fig. 21
00:23
