Nuova Simonelli PRONTOBAR - Annual Group Unit Maintenance

17.5
SERVICE MANUAL
Edition 02 to 02/2014
17.4 ANNUALLY MAINTENANCE OR 50.000 CYCLES FOR THE
GROUP UNIT (MANDATORY)
STEPS SEE PAR.
 Remove and clean the group unit
 Remove the motor 3.2
 Remove the upper and lower piston and lower springs
4.1.1
4.1.2
 Disassemble the upper and lower piston showers and gasket
4.1.1
4.1.2
 Remove the movement screw then disassemble the bearings, the support
and the bushing
3.4
 Remove the two guides 3.5
 Remove the group chamber, the heating element and temperature probe 3.3 - 3.5
 Remove the scoop cam, scoop cam shaft and spring 3.6
 Disassemble the teflon plate and plastic movement screw nut
 Remove the scoop cam driver 3.6
 Clean everything
 Rebuild brew unit including replacement of
 Upper and lower piston gasket 02290021, 02290019
4.1.1
4.1.2
 The washer of the upper piston 073300265
 Upper and lower piston shower 2x 03000069
4.1.1
4.1.2
 Scoop cam driver 05000737 3.6
 Scoop cam spring 08000085 3.6
 Plastic movement nut 0500744.1 3.5
 All other wear and tear component
 Clean the movement guides 07300566 4.1.3
 Lubricate the movement screw bearings 08000071 with Nuova Simonelli silicon
grease
4.1.3
 Lubricate with Teflon spray the bushes and the movement screw near the plastic
nut and clean with a dry cloth
4.1.3
Average time for maintenance: 2h
List of replaced parts: 02290021, 02290019, 05000737, 2x 03000069, 08000085, 0500744.1
