The boilers are accessible from the back panel.
The machine must be switched off.
1 Remove the rear panel with a Phillips screw-
driver.
2 Remove the tank (only in the tank version).
3 With a Phillips screwdriver remove the top
screw and loosen the bottom one on the
inner panel.
4 Prontobar has two boilers, one for the coffee
and the other for the steam. The boilers hold
0.8 liters each. Both are stainless steel, insu-
lated and use 1000W heating element each.
Edition 02 to 02/2014
6.2
SERVICE MANUAL
Fig. 133
00:05
Fig. 135
00:22
Fig. 134
00:14
Fig. 136
00:31
