5 Remove the left side panel.
6 Please note that the two versions of the
machine presents some differences:
In the tank version are:
(A) Tank water level sensor (Fig. 211).
(B) Water tank connection (Fig. 212).
Edition 02 to 02/2014
9.3
SERVICE MANUAL
5
Fig. 211
00:18
A
Fig. 212
00:22
B
Fig. 213
00:24
