5 Disconnect the capacitor undoing the screw
with a phillips screwdriver.
6 With a phillips screwdriver, undo the screw
clump, disconnect the wires and slide out
the motor from the right side of the machine.
Edition 02 to 02/2014
9.7
SERVICE MANUAL
Fig. 222
Fig. 223
Fig. 221
