41956001TH Rev.6 151 /
Oki Data CONFIDENTIAL
(13) Low-voltage PWB
(14) Color Registration Sensor PWB (Side L:Z7L, Side R:Z7R)
(15) Humidity Sensor
(16) Density Sensor
Z7L Z7R
CN7
CN5
CN8 CN9 CN10
ACIN
CN1
CN4-2
CN4-1
(CN6-2)
(CN6-1)
CN2
CN3
F1
F2
