41956001TH Rev.6 23 /
Oki Data CONFIDENTIAL
2
1
1
1
2.3.1 Top cover
(1) Open the top cover Assy.
(2) Unscrew 9 screws 1 to detach the top cover 2.
Figure 2-3-1 Top Cover
