Connectors
2.3.20 Color Registration Sensor Assy
(1) Unscrew 2 screws 1, unplug 3 connectors and remove the Color Registration Sensor Assy 2.
(2) Remove the Earth Plate (B) 3.
Figure 2-3-20 Color Registration Sensor Assy
