Oki C9500 - Eject Sensor Assy

41956001TH Rev.6 52 /
Oki Data CONFIDENTIAL
1
2
2.3.29 Eject Sensor Assy
(1) Remove the Fuser Eject Roller. (See Sec. 2.3.28.)
(2) Unscrew the screw 1, unplug the connector and remove the (red/blue) Eject Sensor Assy 2.
Figure 2-3-29 Eject Sensor Assy
