Troubleshooting
6-18 OPERATION GUIDE
Inside the Left Covers 1, 2 and 3
Follow the steps below to clear paper jams inside left cover 1, 2 or 3 when
using the optional paper feeder.
1
Open the left cover where the
paper is jammed inside.
2
Remove the jammed paper.
If the paper tears, remove
every loose scrap from inside
the machine.
3
Close the left cover.
Duplex Unit
Follow the steps below to clear paper jams in the duplex unit.
1
Pull up left cover 1 lever and
open the left cover.
To Next Page
