16 PC operating system language 77
17 VS200 ASW software setup 78
18 VS200 device configuration 85
18.1 Activate the motorized polarizer 86
18.2 Activate the VS200 liquid dispenser 86
18.3 Device settings - objectives 87
18.4 Device settings - filter 88
18.5 Manual device configuration 89
18.5.1 ORCA monochrome camera 90
18.6 Device customization 90
18.6.1 ORCA camera adjustments 91
18.6.2 Setup phase contrast (PH) observation method 92
18.6.3 Setup polarization (Pol) observation method 94
18.6.4 Create or adjust an observation method 95
18.7 VS200 LED lamp voltages 97
18.7.1 Orca Flash 4.0 voltages (%) 97
18.7.2 Orca Fusion voltages (%) 97
18.7.3 VS-304M voltages (%) 98
18.7.4 VS-264C voltages (%) 98
19 How to insert a slide into a tray 99
19.1 How to insert a tray into the VS200 scanner 99
19.2 Insert a tray into the VS200 loader 100
20 Calibrate VS200 using the Olympus Calibration Slide 101
20.1 Stage limits - Z Axis 103
20.2 Camera adapter calibration for iDS (VS-264C) camera 106
20.3 Camera-To-Stage Rotation 110
20.4 XY Objective Shift / Parfocality 112
20.5 Shading Correction (Brightfield) 115
20.6 Shading correction of the label area 123
20.6.1 Preparation of calibration slide 123
20.6.2 Shading correction for polarization (Pol) 131
20.7 Magnification Test Scan 136
21 Additional calibrations for a fluorescence system 138
21.1 Camera adapter 139
21.1.1 Camera adapter U-FFWO T3 139
21.2 Camera-To-Stage Rotation 144
21.3 Camera shift 146
- 5 -
Instructions for useOLYMPUS VS200 System
