12 Assembly of the housing for scanner
4. In case you use a U-FFWO make sure that the cable is guided through the
housing like in the image below.
If the top panels are mounted correctly, it should look like this:
5. Connect the two grounding flags to their counter plugs on the right and
left side like shown in the image below.
Left side Right side
- 69 -
Instructions for useOLYMPUS VS200 System
