4-2 Function Mode
4
Functions
1007h Multi-function input monitor d005 R
0 to 63
Multi-function input status, Bit 0 = [1] to
Bit 4 = [5]
⎯
1008h Multi-function output monitor d006 R
0 to 7
Multi-function output status,
Bit 0 = [P1]
Bit 1 = Not used.
Bit 2 = [MA]
⎯
1009h
Output frequency monitor
(after conversion)
d007
(MSB)
R 0 to 3996000 0.01
100Ah
d007
(LSB)
100Ch Output voltage monitor d013 R 0 to 20000 0.01 [%]
100Eh
Total RUN time
d016
(MSB)
R 0 to 999999 1 [h]
100Fh
d016
(LSB)
1010h
Power ON time monitor
d017
(MSB)
R 0 to 999999 1 [h]
1011h
d017
(LSB)
116Ah Fin temperature monitor d018 R 0 to 2000 0.1 [°C]
0011h Fault frequency monitor d080 R 0 to 65535 ⎯
116Ch DC voltage monitor d102 R 0 to 9999 0.1 [V]
116Dh Electronic thermal monitor d104 R 0 to 1000 0.1 [%]
0012h
Fault monitor 1 d081
R Trip monitor 1: Factor code ⎯
0014h R Trip monitor 1: Frequency 0.1 [Hz]
0016h R Trip monitor 1: Current 0.1 [A]
0017h R Trip monitor 1: Voltage 1. [V]
0018h R Trip monitor 1: Run time (MSB)
1. [h]
0019h R Trip monitor 1: Run time (LSB)
001Ah R Trip monitor 1: ON time (MSB)
1. [h]
001Bh R Trip monitor 1: ON time (LSB)
001Ch
Fault monitor 2 d082
R Trip monitor 2: Factor code ⎯
001Eh R Trip monitor 2: Frequency 0.1 [Hz]
0020h R Trip monitor 2: Current 0.1 [A]
0021h R Trip monitor 2: Voltage 1. [V]
0022h R Trip monitor 2: Run time (MSB)
1. [h]
0023h R Trip monitor 2: Run time (LSB)
0024h R Trip monitor 2: ON time (MSB)
1. [h]
0025h R Trip monitor 2: ON time (LSB)
