4-94
4-2 Function Mode
4
Functions
0026h
Fault monitor 3 d083
R Trip monitor 3: Factor code ⎯
0028h R Trip monitor 3: Frequency 0.1 [Hz]
002Ah R Trip monitor 3: Current 0.1 [A]
002Bh R Trip monitor 3: Voltage 1. [V]
002Ch R Trip monitor 3: Run time (MSB)
1. [h]
002Dh R Trip monitor 3: Run time (LSB)
002Eh R Trip monitor 3: ON time (MSB)
1. [h]
002Fh R Trip monitor 3: ON time (LSB)
1014h
Acceleration time 1
F002
(MSB)
R/W
1 to 300000
The second decimal place is ignored
when the value is over 10000 (100.0
seconds).
0.01 [s]
1015h
F002
(LSB)
R/W
1501h
2nd acceleration time 1
F202
(MSB)
R/W
1 to 300000
The second decimal place is ignored
when the value is over 10000 (100.0
seconds).
0.01 [s]
1502h
F202
(LSB)
R/W
1016h
Deceleration time 1
F003
(MSB)
R/W
1 to 300000
The second decimal place is ignored
when the value is over 10000 (100.0
seconds).
0.01 [s]
1017h
F003
(LSB)
R/W
1503h
2nd deceleration time 1
F203
(MSB)
R/W
1 to 300000
The second decimal place is ignored
when the value is over 10000 (100.0
seconds).
0.01 [s]
1504h
F203
(LSB)
R/W
1018h
Operator rotation direction
selection
F004 R/W 0: Forward 1: Reverse ⎯
1019h
Frequency reference
selection
A001 R/W
00: Digital Operator (volume)
01: Terminal
02: Digital Operator (F001)
03: ModBus communication
10: Frequency operation result
⎯
101Ah RUN command selection A002 R/W
01: Terminal
02: Digital Operator
03: ModBus communication
101Bh Base frequency A003 R/W 30. to maximum frequency A004 1. [Hz]
150Ch 2nd base frequency A203 R/W 30. to maximum frequency A204 1. [Hz]
101Ch Maximum frequency A004 R/W 30 to 400 1. [Hz]
150Dh 2nd maximum frequency A204 R/W 30 to 400 1. [Hz]
101Dh FV/FI selection A005 R/W
02: Switches between FV/VR via
terminal AT
03: Switches between FI/VR via terminal
AT
04: Terminal FV
05: Terminal FI
⎯
Register
No.
Function name
Parameter
No.
R/W
Function
Monitor or data range
Resolution
